Category:Western Digital Marvell Pinclite

Pinclite

Top lid of a WD3200AAKS-00L9A0 drive.

CrystalDiskInfo printout of SMART attributes.

Module C5 name

PINCLITE

Namesake

Pinnacles; the "lite" designates a new revision.

R/N

701590

Form factor

3.5"

z-height (mm)

26.1"

Basic specifications

Speed (RPM)

7,200

Cache

8,192 or 16,384 kB

Advanced Format?

No

Maximum transfer speed (MB/s)

126

Interface specification

Interface(s)

SATA

Interface version(s)

SATA 2.5 (300 MB/s)

Recording internals

Maximum platters

1

Capacity per platter

320 GB

Recording method

CMR

MCU model number

88i8846-TFJ2

Cross-compatible families

None

Product availability

First released

2009

Last discontinued

2011

Predecessor	Successor
STG Twin Lakes (last density predecessor) Pinnacle (previous revision)	Tahoe/Tahoe LT/Tahoe PL/Tahoe XL

Capacity predecessor	Capacity successor
None	None

HDA predecessor	HDA successor
None	None

This category lists all Western Digital drives that are members of the WD Marvell family Pinclite (short for Pinnacle Lite). Pinclite introduces a new R/N identical to the much rarer Midori, and a new spindle motor that also sounds similar. Internally, a new MCU is used, the 88i8846-TFJ2, once again separating cache RAM from the MCU.

This category currently contains no pages or media.
